VMC Unit 550 m³/h - Compact - Lightweight - Affordable - Quiet

250 m³/h mechanical ventilation unit

550 m³/h 230 V VMC Unit

250 m³/h mechanical ventilation unit

250 m³/h mechanical ventilation unit

250 m³/h mechanical ventilation unit

550 m³/h 230 V VMC Unit

250 m³/h mechanical ventilation unit

250 m³/h mechanical ventilation unit

Motorized air handling unit ideal for mechanical ventilation systems in commercial and service sector buildings, apartments, restrooms, etc.

- Inlet/outlet dimensions: D 160 mm
—L 320 x D 380 x H 320 mm
- 230V - 0.68A - 160W - 550 m³/h at 0 Pa
- Quiet at 30 dB and lightweight at 5 kg
- Horizontal mounting, indoor installation.
- Thick polypropylene panels and galvanized steel motor
- Removable opening secured with screws
- Galvanized circular connectors included (160, PVC).
- Direct-coupled motor-fan unit

- Not compatible with a range hood or public access facilities (C4 F400-compliant unit)

For more power and high quality:500 m³/h mechanical ventilation unit

Quantity

198.00 Tax excluded

237,6 € TTC

Last items in stock

Fast delivery

Advisers 5 days a week

Payment in 3 or 4 instalments

Description
Product Details

Motorized Exhaust Unit for Mechanical Ventilation Systems

Benefits of the 550 m³/h motorized unit for mechanical ventilation systems:

• Exhaust unit with a maximum exhaust volume of 550 m³/h
• Versatile motorized unit that can be used for exhaust (suction), supply (blowing), or transfer
• Ventilation unit with an extra-flat design allowing installation in tight spaces, ideal for drop ceilings or attics with low ceilings
• Easy-to-install unit for integration into controlled mechanical ventilation (CMV) systems, without requiring major construction work
• Motor unit designed to consume less energy while ensuring efficient ventilation of indoor spaces
• Helps renew indoor air, reducing CO₂ levels and pollutants for a healthier environment
• Constructed from durable yet ultra-lightweight materials

Product Details

Brand Ventilsogood

Reference caissonpoly550

Manufacturing: Made in Europe
Warranty: 1 year
Engine: Motorized cabinet
Food: 230V Mono
Engine power: 0 to 2,000 m³/h

ean13 0657968603943
