2-Speed VMC Button
The 2-Speed VMC Button lets you manually switch between low speed and high speed on your extraction fan box, to adjust airflow according to room occupancy.
- Function: low speed / high speed switching
- Enclosure: PVC or ABS IP65, surface mounted
- Thermal protection: not built in
- Warranty: 1 year, subject to professional installation
- Weight: 0.5 kg
Fast delivery
Advisers 5 days a week
Payment in 3 or 4 instalments
The 2-Speed VMC Button is a control switch that lets you toggle between low speed and high speed on a commercial or communal mechanical ventilation installation. Handy for matching airflow to actual room occupancy, without touching the motor itself.
A simple switch to control your mechanical ventilation system day to day
This 2-speed button is surface mounted near the room being ventilated, and gives the user control to select the right speed: low speed running continuously, high speed during occupied periods or when demand is higher. It is designed for communal and commercial mechanical ventilation systems, in buildings fitted with an extraction fan box or a motor running on two speeds.
Technical specifications
| Specification | Value |
|---|---|
| Function | Low speed / high speed switch |
| Enclosure | PVC IP65 (surface mounted) or ABS IP65 with cable glands |
| Thermal protection | Not built in |
| Manufactured in | China |
| Weight | 0.5 kg (1 kg parcel) |
| Warranty | 1 year, subject to conditions |
Installation and wiring
The IP65 enclosure allows surface mounting, including in slightly damp environments. Electrical connection must always be carried out by a qualified professional: this switch has no built in thermal protection against overheating or overcurrent. The 1 year warranty applies only if installation is carried out by a professional and if a compliant thermal protection device is fitted in addition on the motor circuit.
Points to check before ordering
- Check that your motor or fan box runs on two distinct speeds (low and high): this switch is not suitable for a single-speed motor or an electronic speed controller.
- Make sure a compliant thermal protection device will be fitted on the circuit, as this switch does not include one as standard.
- Check the voltage and current rating of your motor with your installer to confirm compatibility with the electrical circuit.
- Have the wiring carried out by a professional: this is a warranty condition.
- If you need a third position (off or intermediate speed), consider a 3-speed model instead.
Pairs well with
Product Details
- Products
- Button / Switch
- Manufacturing
- Made in China
- Warranty
- 1 year
- Package weight
- 1 kg
You might also like
8 other products in the same category:
Frequently asked questions
Does this 2-speed VMC button have an off position?
The available information for this switch does not mention a dedicated off position: it is a button that switches between low speed and high speed only. To cut the ventilation off completely, check the options available on your installation with your installer.
Does the switch include thermal protection?
No, this 2-Speed VMC Button is supplied without thermal protection against overheating or overcurrent. A compliant protection device must be added to the circuit, and this is in fact a condition for the 1 year warranty to apply.
Which IP rating should I choose for a damp room installation?
This switch has an IP65 enclosure, in PVC or ABS depending on the version, which makes it suitable for surface mounting even in slightly damp environments. Check the specific conditions of your room before installation.
Does the warranty apply if I install the switch myself?
The 1 year warranty on this 2-Speed VMC Button is conditional on installation by a professional and on adding a compliant thermal protection device to the motor circuit. A non-professional installation, or one without this protection, may void the warranty.
Does this button work with all MVHR motors?
This switch only works with motors or fan boxes designed for two distinct speeds, low and high. It is not suitable for a single-speed motor or for an electronic controller such as a speed controller or variable frequency drive.
