500x500 Curved Galvanized Cover Plate
The 500x500 Curved Galvanized Cover Plate makes room inside your extraction hood to fit a double-inlet centrifugal fan that's too bulky to sit behind the filters. A simple, sturdy solution for a repair job or fan replacement.
- Size: 500 x 500 mm
- Material: galvanized steel
- Shape: curved, to gain extra usable volume
- Replaces a flat filter or cover plate of 500 x 500
- Package weight: 3 kg
Fast delivery
Advisers 5 days a week
Payment in 3 or 4 instalments
The 500x500 Curved Galvanized Cover Plate is a galvanized steel blanking plate that closes off a filter slot in a commercial kitchen hood, freeing up the space needed for a double-inlet centrifugal fan that's too large to fit behind standard filters.
Why a curved shape rather than a flat plate?
The curved shape of this cover plate isn't just for looks: it creates extra volume inside the hood canopy, exactly where a double-inlet centrifugal fan needs room to breathe. When a flat plate is no longer enough because the fan touches or jams, switching to a curved version is often the simplest fix, with no need to modify the hood itself.
Technical specifications
| Specification | Value |
|---|---|
| Size | 500 x 500 mm |
| Shape | Curved |
| Material | Galvanized steel |
| Manufacturing | Made in Europe |
| Package weight | 3 kg |
| Warranty | 1 year |
Use and compatibility
This cover plate replaces a flat filter or cover plate of 500 x 500 mm in a stainless steel commercial kitchen hood for restaurants, fast-food outlets, kebab shops, snack bars or brasseries. It fits into the original filter slot, with no modification to the hood structure required.
Points to check before ordering
- Measure the filter slot or existing cover plate precisely: this is a fixed-size reference at 500 x 500 mm, not made to measure.
- Check that your fan is indeed a double-inlet centrifugal type requiring this extra volume, rather than simply a fixing issue.
- Check the depth available inside your hood: the curved shape gains volume, but remains limited by the overall size of the canopy.
- If a filter slot is left open without a cover plate, air can pass through this area of least resistance instead of through the filters: properly closing off every slot remains essential for correct extraction performance.
Often bought together
Product Details
- Products
- Shutter
- Manufacturing
- Made in Europe
- Warranty
- 1 year
- Package weight
- 3 kg
8 other products in the same category:
Frequently asked questions
What's the difference between a curved and a flat cover plate for a kitchen hood?
A flat cover plate simply closes off a filter slot. The curved version does the same job while also creating extra volume inside the canopy, useful when a double-inlet centrifugal fan is too bulky to fit behind the filters with a flat plate.
Is the 500x500 curved cover plate compatible with all 500x500 hoods?
This curved galvanized cover plate is designed to replace a flat filter or cover plate measuring 500 x 500 mm. Check this dimension on your hood or on the existing part before ordering, as this is a fixed-size reference.
How do I know if I need a curved cover plate rather than a flat plate?
If your fan touches or doesn't fully fit behind the filters with a flat cover plate, the curved shape provides the extra volume needed. If in doubt about clearance, measure the depth available inside your hood before choosing.
Why does every filter slot in a hood need to be closed off?
If a slot is left open with no filter or cover plate, air tends to pass through this area of least resistance instead of through the grease filters. A curved or flat cover plate ensures air flows correctly through the filters as intended.
